20/20 Imaging 1012V Tethered DR Detector

Modernize Compatible X-Ray Systems with a Compact 10 × 12 Tethered DR Detector

The 20/20 Imaging 1012V combines a compact cassette-sized detector with permanent wired communication to support dependable digital radiography. Its 10 × 12-inch imaging area is well suited for facilities performing routine extremity imaging, specialty examinations, and digital radiography upgrades while maintaining compatibility with supported imaging environments.

Key Benefits

• • 10 × 12-inch (25.4 × 30.5 cm) imaging area
  • Cassette-sized detector design
  • Enhanced Cesium (CsI) scintillator
  • Permanent wired detector communication
  • 16-bit image acquisition
  • Off-center imaging capability
  • Three-year manufacturer warranty

The 20/20 Imaging 1012V combines a compact detector size, permanent wired communication, and a cassette-sized design to support dependable digital radiography across a wide range of imaging environments. Whether modernizing an existing X-ray room or integrating into a new installation, the detector is designed to simplify everyday imaging workflows.

When a Compact 10 × 12 Detector Fits Your Workflow

Upgrade Existing X-Ray Equipment to Digital Radiography

Facilities looking to transition from film or computed radiography (CR) to digital radiography often want to preserve their investment in compatible X-ray equipment. The cassette-sized 20/20 Imaging 1012V supports many DR retrofit projects by allowing practices to modernize image acquisition without replacing an entire compatible imaging room.

Designed for Extremity Imaging & Smaller Anatomy

The compact 10 × 12 imaging area simplifies positioning during examinations involving the foot, ankle, hand, wrist, elbow, and other smaller anatomy where a full-size detector may be unnecessary.

Continuous Detector Communication for Fixed Imaging Rooms

The 1012V detector maintains a continuous wired connection to the acquisition workstation, making it well suited for dedicated imaging rooms where consistent detector communication is preferred throughout the workday.

Where the 1012V Fits Into Clinical Practice

The compact detector size and tethered workflow make the 20/20 Imaging 1012V well suited for facilities performing routine digital radiography in dedicated imaging rooms.

Common Imaging Environments

• • Podiatry practices
  • Orthopedic clinics
  • Chiropractic practices
  • Veterinary practices
  • Urgent care centers
  • Specialty medical offices
  • General radiography rooms

Common Radiographic Examinations

The compact 10 × 12 detector is particularly well suited for imaging smaller anatomy, including:

• • Foot and ankle imaging
  • Hand and wrist imaging
  • Extremity studies
  • Musculoskeletal imaging
  • General radiography, depending on the compatible imaging system

How the 1012V Fits Into Different Imaging Workflows

Upgrade Compatible X-Ray Rooms to Digital Radiography

The cassette-sized detector design makes the 1012V detector well suited for compatible DR retrofit projects. Facilities upgrading from film or computed radiography (CR) can often transition to digital radiography without replacing the entire compatible X-ray system, helping preserve existing equipment while modernizing image acquisition.

Integrate Into New Digital Radiography Installations

The detector can also be incorporated into compatible digital radiography systems where a compact tethered detector best supports the clinical workflow. Its permanent wired connection and 10 × 12 imaging area make it a practical choice for dedicated imaging rooms, specialty practices, and new digital imaging installations that benefit from a compact detector.

Detector Technologies Built Into the 1012V

Enhanced Cesium (CsI) Scintillator

The 20/20 Imaging 1012V uses an enhanced Cesium Iodide (CsI) scintillator that efficiently converts X-ray energy into digital image data. Its columnar crystal structure helps improve detector efficiency while supporting excellent image quality at lower radiation doses.

16-Bit Image Acquisition

The detector captures images using 16-bit acquisition, providing a broad grayscale range that supports detailed visualization across routine digital radiography examinations.

Off-Center Imaging Capability

Off-center imaging provides additional positioning flexibility during compatible examinations, allowing technologists to position anatomy more naturally without requiring perfect detector centering.

Compatible Imaging Platforms

The 20/20 Imaging 1012V is designed for compatible digital radiography systems that support the detector, acquisition software, and overall imaging workflow. Compatibility depends on detector integration, workstation software, and the imaging system configuration.

Acquisition Software Designed for the 1012V

The 20/20 Imaging 1012V integrates with compatible acquisition software to support image capture, image enhancement, DICOM communication, image review, and routine digital radiography workflow. Available software capabilities vary depending on the imaging system configuration.

Why the 20/20 Imaging 1012V Stands Out

Whether upgrading a compatible X-ray room to digital radiography or integrating a compact detector into a new imaging installation, the 20/20 Imaging 1012V provides dependable tethered performance in a cassette-sized form factor. Its compact footprint, enhanced Cesium scintillator, permanent wired communication, and flexible deployment options make it a practical solution for facilities seeking efficient digital radiography without unnecessary workflow complexity.

Compare 20/20 Imaging DR Detector Options

• Need a full-size detector for routine digital radiography? Explore the 20/20 Imaging 17 × 17 DR Detector.
• Need a detector designed for single-exposure spine and long-leg imaging? Explore the 20/20 Imaging 17 × 48 Long-Length DR Panel.

20/20 Imaging 1012V Tethered DR Detector Specifications

Detector Specifications

• • Detector size: 10 × 12 in. (25.4 × 30.5 cm)
  • Active imaging area: 10 × 12 in. (25.4 × 30.5 cm)
  • Cassette-sized detector
  • Enhanced Cesium (CsI) scintillator
  • Weight: approximately 5.5 lbs. (2.5 kg)
  • Pixel matrix: 2,000 × 2,400
  • Resolution: 4.0 lp/mm
  • 16-bit A/D conversion

Workflow & Connectivity

• • Permanent tethered detector communication
  • Off-center imaging capability
  • Compatible workstation integration
  • Designed for fixed-room and DR retrofit applications

Warranty

• • Three-year manufacturer warranty
