Rayence Xmaru 1417WCC/WGC Wireless DR Panel

Standard 14 × 17 Detector Size for Everyday Digital Radiography

The Rayence Xmaru 1417WCC/WGC is built around the industry’s most common detector size for general digital radiography. Its 14 × 17-inch imaging area, wireless operation, and ISO 4090 cassette dimensions allow compatible radiographic rooms to transition to DR while preserving familiar positioning techniques and existing cassette tray infrastructure.

• Standard 14 × 17-inch (384 × 460 mm) wireless detector
• Fits compatible ISO 4090 cassette tray installations
• Available in WCC (CsI) and WGC (GOS) configurations
• Optional GigE or C-Link connectivity

Because the detector follows standard cassette dimensions, many facilities can modernize compatible imaging rooms without replacing existing buckys or significantly changing established imaging workflows.



When a 14 × 17 Detector Is the Right Choice

The Standard Detector Size for General Radiography

A 14 × 17 detector provides the imaging coverage used for many routine radiographic examinations while maintaining a familiar cassette format. It offers a balance between detector coverage, positioning flexibility, and compatibility with existing radiographic equipment.

Benefits include:

• • Standard 14 × 17-inch imaging area
  • Supports a wide range of general radiography examinations
  • Familiar cassette dimensions for compatible imaging rooms
  • Wireless workflow without changing established positioning techniques

Wireless Features That Simplify Daily Imaging

The Rayence Xmaru 1417WCC/WGC combines wireless detector operation with workflow features designed to support efficient imaging throughout the day.

Auto-AED Exposure Detection

Automatically detects X-ray exposure from compatible generators without requiring a dedicated synchronization connection.

Built-In Image Storage

Internal detector memory temporarily stores images during wireless interruptions until communication is restored.

OLED Status Display

An integrated OLED display provides battery level, wireless connection status, and detector operating information directly on the detector.

Hot-Swappable Battery

The removable battery design allows batteries to be exchanged quickly to help minimize workflow interruptions.

Designed for Compatible DR Retrofit Projects & General Radiography

Compatible X-Ray Systems

The Rayence Xmaru 1417WCC/WGC is designed for compatible radiographic systems using ISO 4090 cassette dimensions and supports digital radiography upgrades without extensive equipment modifications.

Compatible installations may include:

• • Fixed radiographic rooms
  • Compatible mobile X-ray systems
  • DR retrofit projects
  • Existing ISO 4090 cassette tray installations

Clinical Environments That Benefit From a 14 × 17 Detector

The standard detector size makes the Rayence Xmaru 1417WCC/WGC suitable for facilities performing a broad range of routine digital radiography examinations.

Common clinical environments include:

• • Hospitals and health systems
  • Medical imaging centers
  • Orthopedic practices
  • Chiropractic clinics
  • Outpatient imaging centers
  • Veterinary imaging facilities

Choose Between WCC & WGC Detector Configurations

The Rayence Xmaru 1417 is available in two wireless detector configurations.

Xmaru 1417WCC

The WCC configuration uses a Cesium Iodide (CsI) scintillator.

CsI uses a columnar crystal structure that helps direct light more efficiently through the detector. This can improve detector efficiency and support excellent image quality at lower radiation doses.

Xmaru 1417WGC

The WGC configuration uses a Gadolinium Oxysulfide (GOS) scintillator.

GOS is a well-established scintillator technology that provides dependable image quality while offering an alternative detector configuration based on facility preferences and imaging requirements.

Both configurations share the same detector dimensions, wireless workflow, housing, and core specifications. The primary difference is the scintillator technology selected during system configuration.



Compare the Rayence Xmaru Detector Family

The Rayence Xmaru Series includes detector sizes and connectivity options designed to support different imaging workflows.

Need a compact detector for smaller imaging areas or improved positioning flexibility? Explore the Rayence Xmaru 1012WCC/WGC.

Need the largest wireless imaging area for general radiography? Explore the Rayence Xmaru 1717WCC/WGC.

Prefer a tethered 17 × 17 detector for a dedicated fixed imaging room? Explore the Rayence Xmaru 1717SCC/SGC.



---

Rayence Xmaru 1417WCC/WGC Specifications

Detector Dimensions

• • Detector Size: 384 × 460 × 15 mm (14 × 17 × 0.6 in.)
  • Active Imaging Area: 358 × 430 mm (14.1 × 16.9 in.)
  • Weight: Approximately 3.4 kg (7.5 lbs.) including battery

Image Performance

• • Pixel pitch: 127 μm or 140 μm (configuration dependent)
  • Pixel matrix: Up to 2,816 × 3,392
  • Limiting resolution: Up to 3.93 lp/mm
  • A/D conversion: 14-bit / 16-bit
  • Preview image: Less than 2 seconds
  • Energy range: 40 to 150 kVp

Construction & Durability

• • Carbon fiber detector housing
  • Thin cassette-sized profile
  • IPX6 water-resistant enclosure
  • Recessed detector edges
  • Uniform load capacity: 300 kg (661 lbs.)
  • Point load capacity: 150 kg (330 lbs.)

Connectivity & Workflow

• • Wireless communication
  • Optional GigE or C-Link interface
  • Auto-AED exposure detection
  • Built-in image storage
  • OLED status display
  • Hot-swappable battery
  • Automatic image orientation
