Konica Minolta Automated Overhead Tube Crane (OTC) X-Ray System

Built for Modern Radiography Workflows

The Konica Minolta Automated OTC is designed to help technologists move efficiently throughout the imaging day. Automated positioning and tracking functions reduce the need for manual adjustments while helping maintain accurate alignment between the X-ray tube and detector.

The system supports both table and upright imaging workflows and can automatically position itself based on preconfigured exam settings. This helps standardize common exams, improve positioning consistency, and reduce setup time.

Patient-side controls further streamline operation by providing access to positioning and generator functions directly at the exam area rather than requiring repeated trips back to the workstation.

Workflow Advantages

• • Automated tube positioning
  • Auto-tracking functionality
  • Auto-centering capability
  • Patient-side positioning controls
  • Off-center imaging support
  • Optional auto-stitching functionality
  • Automatic Exposure Control (AEC)
  • Anatomical programming access

Key Features

Automated Positioning

The Automated OTC supports preconfigured positioning for both table and wall stand imaging. When an exam is selected, the system automatically moves the tube suspension to the appropriate source-to-image distance (SID) and detector alignment, helping reduce setup time and improve positioning consistency.

Auto-positioning can be configured for both table and upright imaging workflows, allowing technologists to move quickly between common exam types with minimal manual repositioning.

Intelligent Auto-Tracking

The system offers automated tracking functionality that continuously maintains alignment between the X-ray tube and detector as components move throughout the room.

For upright imaging, the suspension automatically tracks detector movement and maintains proper source-to-image distance as the wall stand position changes. Even during wall stand tilt movements, the system helps maintain consistent imaging geometry by preserving detector alignment and SID relationships.

Two tracking modes are available:

• • Fully automated tracking that follows detector movement throughout its range of motion
  • Tracker mode that automatically aligns the tube and detector from existing imaging positions

Patient-Side Control Console

The integrated control station provides direct access to positioning information and imaging controls, allowing technologists to make adjustments without interrupting workflow.

The console displays:

• • Source-to-image distance (SID)
  • Tube rotation angle
  • Horizontal position
  • Patient information
  • Tracking status
  • Auto-centering status
  • Auto-positioning status
  • Generator parameters
  • System status
  • Active workstation information

Flexible Room Coverage

The ceiling suspension system is designed to cover nearly the entire imaging room through extensive longitudinal and transverse travel. This flexibility allows technologists to position the tube efficiently for both table and wall stand examinations while supporting a wide variety of imaging procedures.

Clinical Applications

The Automated OTC is well suited for healthcare organizations that require a versatile digital radiography room capable of supporting both routine and specialized imaging workflows. Its automated positioning and tracking capabilities make it a strong fit for hospitals, outpatient imaging centers, orthopedic practices, chiropractic clinics, multispecialty physician groups, and urgent care facilities.

Orthopedic and Musculoskeletal Imaging

Designed to support high-volume orthopedic workflows, the system accommodates:

• • Extremity imaging
  • Weight-bearing studies
  • Joint imaging
  • Long-length imaging with optional stitching

Chiropractic and Spine Imaging

For practices that routinely perform upright and spinal examinations, the system supports:

• • Cervical spine imaging
  • Thoracic spine imaging
  • Lumbar spine imaging
  • Long-length spine studies with optional stitching

General Diagnostic Radiography

The Automated OTC supports a broad range of routine imaging procedures commonly performed in hospitals and outpatient environments, including:

• • PA chest exams
  • Lateral chest exams
  • Upright chest studies
  • Upright abdominal exams
  • Supine abdominal exams
  • Routine outpatient imaging
  • General hospital radiography

Table and Wall Stand Design

Elevating Radiographic Table

The integrated elevating table is designed to improve patient accessibility while providing the flexibility required for a wide range of imaging procedures. Its flat composite carbon fiber tabletop helps improve patient comfort while minimizing X-ray attenuation.

The table features four-way floating movement with electromagnetic brakes, allowing technologists to position patients efficiently while maintaining stability throughout the exam.

Table Features

• • Four-way floating tabletop
  • Carbon fiber tabletop construction
  • Electromagnetic brakes
  • Detector pull-out access
  • Longitudinal detector travel
  • Patient capacity of 660 lbs.

Motorized Detector and Auto-Centering Operation

When used with the table, both the detector and suspension system operate through motorized movement followed by automatic centering. This coordinated workflow helps maintain alignment while reducing manual positioning requirements during exams.

Tilting Wall Stand

The motorized wall stand supports upright imaging procedures and integrates with the system’s automated positioning and tracking capabilities.

The wall stand is designed to accommodate a variety of patient positions while supporting efficient workflow transitions between upright and table-based exams.

Wall Stand Features

• • Tilting wall stand design
  • Motorized vertical movement
  • Auto-positioning capability
  • Auto-tracking compatibility
  • Fully counterbalanced manual positioning
  • Digital flat panel detector compatibility

Automation and Positioning Technology

Fully Automated Ceiling Suspension

The heavy-duty overhead tube crane is engineered to deliver positioning precision and speed throughout the imaging environment. Its lightweight design supports accurate movement while helping technologists position the tube quickly and efficiently.

The OTC can operate with a horizontal or vertical bucky and may be installed with an elevating table to support a wide range of room configurations.

Key capabilities include:

• • Fully electronic self-positioning
  • Automated tracking
  • Automated centering
  • Automated positioning
  • 360° vertical and horizontal tube rotation

Advanced Tube-to-Detector Synchronization

The Automated OTC’s primary differentiator is its ability to maintain alignment between the X-ray tube and detector throughout positioning workflows.

For wall stand exams, the suspension automatically tracks detector movement while maintaining configured imaging geometry. For table exams, detector and tube movements are coordinated through motorized synchronization and automatic centering functions.

These capabilities help reduce positioning complexity while supporting consistent imaging results across a wide variety of exam types.

Service-Friendly Design

The suspension system incorporates modular electrical assemblies designed to simplify installation, calibration, and maintenance. This modular architecture can help streamline service procedures and support long-term system operation.

Specifications

Ceiling Suspension Tube Crane

• • Fully automated overhead tube crane
  • Electronic self-positioning
  • Auto-positioning functionality
  • Auto-tracking functionality
  • Auto-centering functionality
  • 360° vertical and horizontal tube rotation
  • Plug-in modular electrical assemblies

Ceiling Rail Travel

Longitudinal Travel

132.2 to 236.22 inches

Transverse Travel

78.74 to 135.83 inches

Wall Stand Specifications

• • Tilt range: +90° to -20°
  • Rotation: 90°
  • Motorized vertical travel: 59.06 inches
  • Minimum floor distance: 15.75 inches
  • Maximum floor distance: 74.8 inches
  • Fully counterbalanced positioning

Elevating Table Specifications

• • Table dimensions: 87 in. × 25 in.
  • Patient capacity: 660 lbs.
  • Longitudinal tabletop movement: 43.11 inches
  • Transverse tabletop movement: 9.84 inches
  • Longitudinal detector travel: 24.02 inches
  • Minimum floor-to-table height: 21.65 inches
  • Maximum floor-to-table height: 35.43 inches
  • Carbon fiber tabletop construction
  • Detector pull-out capability
