Mindray Animal Vetus M10 Portable Ultrasound

Mindray Animal Medical Vetus M10: Cart-Quality Portable Ultrasound

The Mindray Animal Medical Vetus M10 is built for practices that want high-end diagnostic capability without committing to a full cart-based system. Using Mindray’s ZST+ platform, it delivers high-resolution imaging and fast processing across a wide range of veterinary applications while maintaining the flexibility of a portable system.

Key Highlights

• • ZST+ platform for advanced image processing and clarity
  • Cart-level image quality in a portable ultrasound system
  • 15.6-inch high-resolution touchscreen display
  • Advanced Doppler and imaging modes for complex diagnostics
  • Built-in battery and wireless connectivity
  • Broad probe compatibility across multiple clinical applications

The system allows practices to perform more advanced imaging without changing how their workflow is structured.

Mindaray Animal Vetus Ultrasound Platform Overview & Workflow Demonstration

This video highlights the Vetus ultrasound platform, including the touchscreen workflow, imaging technologies, and clinical design shared across the Vetus family. While the featured system may differ from the Vetus M10, it provides a representative look at the workflow, usability, and imaging approach used throughout the Vetus lineup.

Delivering Cart-Level Imaging in a Compact & Portable Design

Many veterinary practices need strong imaging performance while maintaining flexibility in how and where the system is used. The Mindray Animal Medical Vetus M10 is designed to support both by combining advanced imaging technology with a portable system design.

ZST+ Platform for High-Resolution Imaging

The Mindray Animal Medical Vetus M10 is powered by Mindray’s ZST+ (Zone Sonography Technology+) platform, which improves image formation by optimizing signal processing at the pixel level. This results in improved contrast resolution, clearer tissue differentiation, and more consistent image quality across exam types.

Advanced Imaging Capability in a Portable System

The system supports more complex diagnostic workflows than typical entry-level portable ultrasound systems, allowing practices to expand imaging capabilities without moving to a cart-based platform.

15.6-Inch Touchscreen for Full-System Control

The Mindray Animal Medical Vetus M10 features a 15.6-inch high-resolution touchscreen that allows users to control imaging parameters, review images, and manage workflows directly from the display.

Built-In Battery & Wireless Connectivity for Flexible Use

The integrated battery supports use across multiple exam rooms, while wireless connectivity allows for image transfer, remote review, and system integration without requiring fixed infrastructure.

Veterinary Practices That Benefit from the Mindray Vetus M10

The Animal Medical Vetus M10 is designed for practices that need higher imaging performance than entry-level systems while maintaining flexibility in how the system is deployed. It is particularly well suited for practices that want advanced diagnostic capability without the size and setup requirements of a cart-based ultrasound system.

Built for Specialty, Emergency & Advanced General Practices

The system is well suited for:

• • • Specialty and referral veterinary practices
    • Emergency and critical care environments
    • Advanced general practices with higher imaging demands
    • Multi-doctor clinics requiring consistent imaging quality

These environments benefit from the system’s ability to support more advanced diagnostics without the footprint of a cart-based ultrasound system.

Abdominal, Cardiac & Advanced Diagnostic Applications

The Vetus M10 supports a wide range of imaging applications, allowing practices to perform both routine and advanced diagnostics on a single system.

• • Abdominal imaging
  • Cardiac imaging and echocardiography
  • Reproductive and pregnancy exams
  • Musculoskeletal (MSK) imaging
  • Vascular assessments
  • Small parts and superficial structure imaging

This range allows practices to expand diagnostic capability without adding multiple ultrasound systems.

Advanced Imaging Modes on the Mindray Animal Medical Vetus M10

The Mindray Animal Medical Vetus M10 includes imaging technologies designed to improve visualization and support more accurate diagnosis across different exam types.

Doppler, Harmonic & Advanced Imaging Modes

The system supports:

• • B-mode and harmonic imaging
  • M-mode and anatomical M-mode
  • Color and power Doppler
  • Pulsed wave and continuous wave Doppler
  • Tissue Doppler imaging
  • Contrast imaging

These modes support both routine exams and more advanced diagnostic workflows such as cardiac and vascular imaging.

Built-In Image Optimization Tools for Consistent Results

The Mindray Animal Medical Vetus M10 includes integrated image optimization technologies that help improve clarity and reduce manual adjustments during exams.

• • iTouch™ automatically optimizes image parameters with a single input, helping standardize image quality across users
  • iClear™ reduces speckle noise to improve tissue clarity and edge definition
  • iBeam™ uses spatial compounding to enhance contrast and improve visualization of anatomical structures

These tools help reduce the need for constant manual tuning while maintaining consistent image quality across different exam types.

Compact Design & Clinical Usability of the Mindray Animal Medical Vetus M10

The Mindray Animal Medical Vetus M10 is designed to support daily clinical use while maintaining flexibility in how the system is positioned and used.

Portable System Designed for Room-to-Room Use

The system can be easily moved between exam rooms or used in different areas of a practice, allowing imaging to be performed where it is needed without relying on a fixed setup.

15.6-Inch Touch Display for Imaging & Workflow Control

The large display provides clear visualization of ultrasound images while allowing full control of system functions through a touch-based interface.

Linear, Convex & Phased Array Probe Support for Multiple Exam Types

The Mindray Animal Medical Vetus M10 supports a range of transducers, including:

• • Linear probes for vascular imaging, musculoskeletal exams, and superficial structures such as tendons, ligaments, and soft tissue masses
  • Convex probes for abdominal imaging, including organ evaluation and general diagnostic scans
  • Phased array probes for cardiac imaging and echocardiography

This allows the system to adapt to different animal sizes and clinical applications without requiring multiple ultrasound platforms.

How the Mindray Animal Vetus M10 Fits Into Daily Workflows

The Mindray Animal Medical Vetus M10 is designed to support efficient imaging from exam setup through image review and documentation. Its interface, preset structure, and integrated tools reduce the number of manual steps required during exams while maintaining control over advanced imaging functions.

Exam Presets for Faster Setup & Consistent Imaging

Customizable exam presets allow users to standardize imaging parameters for different exam types. This reduces setup time and helps ensure consistent image quality across users and patients.

On-Screen Controls for Real-Time Adjustment

Imaging parameters, measurements, and annotations can be adjusted directly from the touchscreen, allowing users to make changes during scanning without shifting between controls or interrupting workflow.

Designed for Multi-User Veterinary Practices

The system supports consistent operation across multiple users by combining standardized presets with intuitive controls, helping reduce variability in image quality between operators.

Connectivity, Image Management & Reporting Capabilities

The Mindray Animal Medical Vetus M10 includes tools for storing, sharing, and documenting ultrasound studies, supporting both internal workflow and communication with referring veterinarians or clients.

Internal Storage for Study Management

The Mindray Animal Medical Vetus M10 includes integrated solid-state storage (SSD) for saving ultrasound images, cine loops, and exam data directly on the system. Storage capacity is configurable and typically sized to support a high volume of studies, allowing practices to store and review exams locally without relying on immediate external transfer.

For most veterinary workflows, this level of onboard storage is sufficient to manage daily imaging volume, including image sequences and longer cine clips. Studies can then be archived, exported, or transferred as needed through DICOM, network connections, or external media.

DICOM Integration for PACS & Image Archiving

DICOM support allows the Vetus M10 to connect with PACS and other imaging systems, enabling structured storage, retrieval, and review of ultrasound studies within a centralized system.

Wireless Data Transfer for Image Sharing

Wireless connectivity allows images and reports to be transferred without relying on physical media, supporting faster collaboration and easier sharing across locations.

Measurement & Reporting Tools for Clinical Documentation

Built-in measurement packages support common veterinary exam types, including abdominal, cardiac, and reproductive studies. These tools help standardize reporting and reduce the need for manual documentation.

Transducer Options & Clinical Flexibility

The Mindray Animal Medical Vetus M10 is designed to support a wide range of clinical applications through compatible probes and procedural accessories.

Linear, Convex & Phased Array Probes for Specific Exam Types

• • Linear probes for vascular imaging, musculoskeletal exams, and superficial structures such as tendons, ligaments, and soft tissue masses
  • Convex probes for abdominal imaging, including organ evaluation and general diagnostic scans
  • Phased array probes for cardiac imaging and echocardiography

This range allows practices to perform multiple exam types without switching systems.

Needle Guidance & Procedural Imaging Support

Compatible needle guides and enhanced visualization tools support ultrasound-guided procedures, improving targeting accuracy during injections, aspirations, and other interventional workflows.

System Configuration & Clinical Integration

The Mindray Animal Medical Vetus M10 is designed to integrate into existing workflows without requiring significant changes to space or infrastructure.

Portable System for Flexible Room-to-Room Use

The system can be moved between exam rooms or used across different areas of a practice, allowing imaging to be performed where it is needed without relying on a fixed installation.

Works Alongside Existing Imaging Infrastructure

With DICOM and network connectivity, the Mindray Vetus M10 can be integrated into practices that already use digital imaging systems, allowing ultrasound to fit into existing data management workflows.

Mindray Animal Medical Vetus M10 Specifications

System

• • Display: 15.6-inch high-resolution touchscreen
  • Interface: Touchscreen with on-screen controls and gesture support
  • Portability: Designed for room-to-room use with integrated battery

Imaging Modes

• • B-mode
  • M-mode and anatomical M-mode
  • Color Doppler
  • Power Doppler
  • Pulsed wave Doppler
  • Continuous wave Doppler
  • Tissue Doppler imaging
  • Contrast imaging

Imaging Technologies

• • ZST+ imaging platform
  • iTouch™ automatic image optimization
  • iClear™ speckle reduction
  • iBeam™ spatial compounding

Connectivity & Storage

• • Internal system storage for ultrasound studies
  • DICOM support for PACS integration
  • Wireless data transfer capabilities
  • USB and network export option

Transducer Support

• • Linear probes
  • Convex probes
  • Phased array probes
  • Needle guide compatibility

Power & Mobility

• • Built-in battery for mobile use
  • Portable system design for flexible positioning
